500 GSM Power Plant Dust Extractor System PPS Filter Bag

PPS needle felt PPS filter bag is the best choice for coal fired boiler in thermal power plant. The operation temperature of PPS filter bags is  up to 190  degree C. It is also the best
PPS Ryton filter bag:
1. Temperature (°C): Continue: 190, Instant: 210
2. Application:waste incinerator,electric station boiler,industry boiler and so on.

Size:
Quantity:
  • PPS160x6000
  • ECOGRACE
  • PPS105

500 GSM Power Plant Dust Extractor System PPS Filter Bag

ECOGRACE is specialized in power plant  bag filters ,  fly ash dust extraction filtation system , air pollution control system ,  our high temperature resistant filter bags are widely applied in power plant in China and oversea countries .

ECOGRACE Dust  Filter bags widely applied in different industrial dust filtration system or air pollution control system dust collector filter  elements.Three  production lines keeps our delivery time always in time for every order .

Types of ECOGRACE Filter bags :
The type of dust filter bags :
Pulse jet filter bag
Reverse pulse filter bag
Envelope type filter bag

The Application /  Industry:
Baghouse Filtration / Air pollution control system

Foundry /  Metal Smelting
Asphalt Mixing
Power Generation ,
Waste treatment power generation plant ,
Cement  , Gypsum / Lime Processing
Mining.
Carbon Black.

1280PECOGRACE is very speciallized in High temperature  filter bags:
Nomex filter bag:
1. Temperature (°C): Continue: 204, Instant: 240
2. Application : pitch mix gas,blast furnace gas in steel factory,

gas, tail gas of white char,kiln applications,electric cooker high temperature gas,etc.
PPS Ryton filter bag:
1. Temperature (°C): Continue: 190, Instant: 210
2. Application:waste incinerator,electric station boiler,industry boiler and so on.
P84 / PI  filter bag  ( Polyimide )

1. Temperature (°C): Continue: 260, Instant: 300
4. Application:cement kiln,waste incinerator,etc
Fiberglass  filter bag:
1.Temperature (°C): Continue: 240, Instant: 260
2.Features:low price compared with other high temperature fibers,and stable size,low
shrinkage rate,high intensity
3.Application:chemistry,steel factory,metallurgy,cement,etc.
Fiberglass Felt filter bag:
1.Temperature (°C): Continue: 260, Instant: 280
2.Features:heavy loads,long life time, reasonable price, strong function etc.
3.Application:polluted air and dust in Iron & Steel factory, Melting factory, Cement factory,Petrol chemistry ,etc.
PTFE  filter bag ,PTFE Fabrics:
1. Temperature (°C): Continue: 250, Instant: 300
2. Features: strong stability, wear resistance, chemical stability, temperature resistance is  particularly prominent
3. Application:used in steel, power, waste incineration flue gas filtration and other harsh  environments.

IMG_0556

 PPS Felt Specification:

Fiber
PPS filter fabric
Weight (g/ m2)
500
Thickness (mm)
1.6
Air permeability (L/m2/s)
200-300
Tensile strength
(N/5 20cm)
wrap
≥1250
weft
≥1350
Broken strength (Mpa/min)
2.6
Continuous/Short time working temperature(℃)
160 /190
Finishing treatment
Heatset and Singed One Side
Anti-acid/alkali/abrasion
Excellent

filter bag pictureProcess
PPS Filter Bags Applications :
• Coal - Fired Boilers bag houses
• Municipal Solid Waste Boilers and Waste incinerator baghouse filter
• Calciners / Catalysts
• Thermal power plant
• Waste to energy
• Iron and non ferrous Metal Industry.
